Product Details:
Payment & Shipping Terms:
|
| Part Number: | 3319-14 3319/4 100 | Packaging Qty: | 100ft Per Reel |
|---|---|---|---|
| Material:: | Polyvinyl Chloride (PVC) | Color: | Black |
| Size: | .050" 28 AWG | Voltage Rating: | 300V |
| Temperature Rating:: | -20°C To +105°C | Flammability Rating:: | VW-1 |
| Number Of Conductors: | 14 Core | ||
| Highlight: | 100FT UL Wire Cable,3319 14 UL Wire Cable,3M Flat Cable 14 Conductors |
||
| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Unconfirmed |
| HTS | 8544.49.90.00 |
| Automotive | No |
| PPAP | No |
| Type | Flat Cable |
| Size (AWG) | 28 |
| Number of Conductors | 14 |
| Factory Cable Length (m) | 30.48 |
| Cable Pitch (mm) | 1.27 |
| Conductor Material | Silver Plated Copper Alloy |
| Jacket Color | Black |
| Maximum Voltage Rating | 300V |
| Impedance (Ohm) | 171 |
| Minimum Operating Temperature (°C) | -20 |
| Maximum Operating Temperature (°C) | 105 |
| Packaging | Roll |
| Product Depth (mm) | 17.78 |
| Product Height (mm) | 0.89 |
| Bunch Stranding | 19x40 |
| Insulation Color | Black |
| Jacket Material | Polyvinyl Chloride |
