Product Details:
Payment & Shipping Terms:
|
| Highlight: | KINGBRIGHT 645 Nm LED,Hyper Red 645 Nm LED,KPED-3528SURCK |
||
|---|---|---|---|
| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| Automotive | No |
| PPAP | No |
| Type | Uni-Color |
| Product Category | Chip LED |
| Color | Red |
| Number of LEDs | 1 |
| LED Material | AlGaInP |
| Lens Shape Type | Circular |
| Lens Dimensions (mm) | 2.6x2.6x1.4 |
| Lens Appearance | Colorless Non Diffused |
| Mounting Orientation | Top Mount |
| Intensity | 800mcd |
| Dominant Wavelength (nm) | 630 |
| Peak Wavelength (nm) | 645 |
| Viewing Angle (°) | 70 |
| Maximum Forward Current (mA) | 30 |
| Test Current (mA) | 20 |
| Maximum Forward Voltage (V) | 2.5 |
| Reverse Voltage (V) | 5 |
| Maximum Power Dissipation (mW) | 75 |
| Minimum Operating Temperature (°C) | -40 |
| Lead Standoff | No |
| Supplier Color | Hyper Red |
| High Power | No |
| High Brightness | No |
| Packaging | Tape and Reel |
| Supplier Package | Chip LED |
| Pin Count | 2 |
| Standard Package Name | Chip LED |
| Mounting | Surface Mount |
| Package Height | 3.2 |
| Package Length | 3.5 |
| Package Width | 2.8 |
| PCB changed | 2 |
| Lead Shape | No Lead |
