| MPN: | D2HW-BL231H | MFR: | OMRON |
|---|---|---|---|
| Category: | Switch | Size: | 10.3*13.3mm |
| Highlight: | D2HW-BL231H SMD DIP Switch,SMD DIP Switch Snap Action,switch snap action 2A 125VAC |
||
| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| Automotive | No |
| PPAP | No |
| Switch Configuration | N.O./N.C. |
| Actuator Style | Simulated Roller Hinge Lever |
| Pole Throw Configuration | SPDT |
| Maximum Current Rating (A) | 2@12VDC |
| Electrical Life (Cycles) | 100000 |
| Mechanical Life (Cycles) | 1000000 |
| Maximum Movement Differential (mm) | 0.5 |
| Mounting | Screw Mount |
| Termination Style | Solder |
| Body Orientation | Straight |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 85 |
| Body Length (mm) | 13.3 |
| Body Depth (mm) | 10.3 |
| Operating Force (N) | 0.65 |
