| MPN: | S2B-PH-K-S | Mfr: | JST |
|---|---|---|---|
| Pitch: | 2 Mm | Pin Number: | 2 Pin |
| Rohs: | Rohs 2.0 | ||
| Highlight: | S2B-PH-K-S PCB Board Connector,JST Conn Shrouded Header,Conn Shrouded Header HDR |
||
| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Part Status | Active |
| Automotive | No |
| PPAP | No |
| Type | Shrouded Header (4 Sides) |
| Gender | HDR |
| Number of Contacts | 2 |
| Number of Rows | 1 |
| Termination Method | Solder |
| Terminal Pitch (mm) | 2 |
| Body Orientation | Right Angle |
| Polarization Type | Center Slot |
| Maximum Current Rating (A) | 2 |
| Maximum Voltage Rating | 100VDC|100VAC |
| Insulation Resistance (MOhm) | 1000 |
| Maximum Contact Resistance (MOhm) | 20 |
| Minimum Operating Temperature (°C) | -25 |
| Maximum Operating Temperature (°C) | 85 |
| Packaging | Box |
| Product Length (mm) | 5.9 |
| Product Depth (mm) | 7.6 |
| Product Height (mm) | 4.8 |
| Tail Length (mm) | 3.4 |
| Mounting | Through Hole |
