Product Details:
Payment & Shipping Terms:
|
| Material: | PA66 | MPN: | B3B-ZR-R |
|---|---|---|---|
| Mfr: | JST | Pitch: | 1.5mm |
| Pin: | 3 Pin | ||
| Highlight: | PCB Board Connector HDR,PCB Board Connector 1.5mm Solder |
||
| EU RoHS | Compliant |
| ECCN (US) | EAR99 |
| Automotive | No |
| PPAP | No |
| Type | Shrouded Header (4 Sides) |
| Gender | HDR |
| Number of Contacts | 3 |
| Number of Rows | 1 |
| Termination Method | Solder |
| Terminal Pitch (mm) | 1.5 |
| Body Orientation | Straight |
| Polarization Type | Dual Slot |
| Maximum Current Rating (A) | 1 |
| Maximum Voltage Rating | 50VDC|50VAC |
| Insulation Resistance (MOhm) | 500 |
| Maximum Contact Resistance (mOhm) | 30 |
| Minimum Operating Temperature (°C) | -25 |
| Maximum Operating Temperature (°C) | 85 |
| Packaging | Box |
| Product Length (mm) | 6 |
| Product Depth (mm) | 3.5 |
| Product Height (mm) | 4.5 |
| Mounting | Through Hole |
